Fiber to Fiber Connector Simplex/Duplex by Unionfiber
Product Description
As an indispensable part of wireless communication base stations, base station patchcord carry the transmission task of RF signals between base station equipment. CPRI, DLC, and PDLC are three common types of base station patch cords, each with different characteristics and application scenarios.
CPRI base station patch cord:
CPRI (Common Radio Frequency Interface) base station patch cord defines the digital interface between Radio Frequency Equipment Control (REC) and Radio Frequency Equipment (RE) of wireless infrastructure base stations.
DLC base station patch cord:
DLC (dual core pull-out) base station patch cord is mainly used for connecting BBU (baseband processing unit) and RRU (radio frequency pull-out module) in 3G networks.
PDLC base station patch cord:
PDLC (Armored Waterproof) base station patch cord has become a standard interface for 3G, 4G, and wireless base station remote radio, fiber to antenna, and other fields.
Product Features
Product Parameters
|
Project |
Technical indicators |
|||
|
Product name |
DLC/PDLC/CPRI Base Station Cable Fiber Optic Patchcord |
|||
|
Parameter |
Unit |
Index |
||
|
Connector Type |
/ |
SM 9/125 |
MM 50/125 |
MM62.5/125 |
|
Insertion Loss |
dB |
Max≤0.7 |
||
|
Repeatability |
dB |
≤0.1 |
||
|
Interchangeability |
dB |
≤0.2 |
||
|
Connection Durability |
dB |
≥500 |
||
|
Operating Temperature |
℃ |
-25~+70 |
||
|
Fiber Type |
SM9/125,MM50/125,MM62.5/125 |
|||
| Parameter | Unit | 9/125 SMF-OS2 | 62.5/125 MMF-OM1 | 50/125 MF-OM2 | 50/125 MMF-OM3 | 50/125 MMF-OM4 |
| Attenuation | dB/Km |
1310nm≤0.35 1550nm≤0.22 |
850 nm≤3.0 1300 nm≤0.8 | 850 nm≤3.0 1300 nm≤0.8 | 850 nm≤3.0 1300 nm≤0.8 | 850 nm≤3.0 1300 nm≤0.8 |
| Dispersion | Ps/nm.km |
1285~1330nm≤3.5 1550nm≤18.0 |
- | - | - | - |
| Fiber Diameter | um | 9/125 um | 50/125 um | 50/125 um | 50/125 um | 50/125 um |
| Effective Modal Bandwidth | EMB | - | 850 nm≥200 | 850 nm≥200 | 850 nm≥200 | 850 nm≥200 |
| Zero Dispersion Wavelength | Nm | 1300-1324 | - | - | - | - |
| Zero Dispersion Slope | Ps/nm.km | ≤0.095 | - | - | - | - |
| Fiber Cutoff Wavelength | Um | ≤1260 | - | - | - | - |
| Mode Field Diameter | Um |
@1310nm-9.2±0.4 @1550nm-10.4±0.8 |
- | - | - | - |
| Mode Field Concentricity | Um | ≤0.8 | - | - | - | - |
| Cladding Diameter | Um | 125±1.0 | 125±2.0 | 125±2.0 | 125±2.0 | 125±2.0 |
| Cladding Non-circularity | % | ≤1.0 | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 |
| Coating/Cladding | Um | ≤12.5 | ≤12.5 | ≤12.5 | ≤12.5 | ≤12.5 |
| Concentricity Error | Um | ≤12.5 | ≤12.5 | ≤12.5 | ≤12.5 | ≤12.5 |
| Coating Diameter | dB/Km | 245±10 | 245±10 | 245±10 | 245±10 | 245±10 |
Application
Product Packaging
The DLC PDLC CPRI Base Station Cable Fiber Optic Patchcord is packed in a PVC bag inside a cardboard box. We support OEM and ODM, catering to either production following your provided design or the creation of a completely customized product from the ground up.
